Item

Specification

3GPP

3GPP protocol

Release 16

5G-4G interworking

NSA option 3/3x，SA option 2

5G

Frequency Band

FDD：N1/3/5/7/8/20/28/71

TDD：N38/40/41/77/78

SUL：N80/81/82/83/84

SDL：N75

Bandwidth

TDD: 100/90/80/70/60/50/40/20/15/10MHz

FDD: 50/40/30/20/15/10/5MHz

DL MIMO

4*4 MIMO DL: N1/3/7/20/28/38/40/41/75/77/78

2*2 MIMO DL: N5/8/71

UL MIMO

2*2: N38/41/77/78 (SA only)

DL/UL modulation

256QAM/256QAM

DL/UL Peak throughput

5G NR 5.4Gbps/500Mbps (@300MHz,SA TDD 8:2 ratio)

No. of Carriers

DL 3CC 300MHz

UL 2CC 200MHz

4G

Frequency Band

B1/3/5/7/8/20/28/32/38/40/41/42/43

MIMO

4*4: B1/3/7/20/28/38/40/41/42/43

2*2: B5/8

DL/UL modulation

256QAM/256QAM

Antenna

Antenna Gain

11dBi

Wi-Fi

Protocol

802.11 n  1*1 MIMO 2.4GHz, used for management purpose only

Feature

Smart Phone APP

Basic Feature

Dimension

197.5mm*126mm*35.5mm

Weight

≈700g (excluding the power adapter)

Interface

1 RJ45*2.5GE, Power*1, SIM*1(4FF)

LED

4G/5G

Button

Reset

Working temperature

-40℃ ～ +55℃, without solar radiation

Waterproof

IP65
